Vehicle Lifts 15K 4-Post Alignment Lift with Extended Runways
Service & Alignment Vehicle Lift
The Autel Alignment 15K Open Post Lift with Ext. Ramps, part number: 415ALOXR1P, is an ALI-certified 4-post alignment lift with a rated capacity of 15,000 lb. and features an open-front design for alignment service. The lift features an overall length of 285-1.8 inches with 237-inch runways, accommodating vehicles up to 164 inches for four-wheel alignments and 220-1.2 inches for two-wheel alignments. Standard alignment equipment includes full-floating rear slip plates, stainless steel front radius plates, and UHMW turn plate pocket protectors. The lift is supplied with two 7,500-lb. heavy-duty air/hydraulic rolling jacks with integrated rail detents for accurate positioning, each backed by a five-year parts warranty. Additional features include a center-mount air outlet kit, an LED light kit, and tire inflation air kits at each wheel. Operation is supported by a 220-volt, single-phase power unit. The lift is finished with black runways and baseframes, yellow front and rear ramps, and red columns, accented by a red Autel logo label. Made in North America.
