Complete ADAS & Alignment Lift Solutions
Repair, Align, & Calibrate With Confidence
ADAS Bay Max Lift
Calibration & Alignment
Alignment Scissor Lift
Flush & Surface Mount
4-Post Vehicle Lift
Open & Closed Front
Vehicle Lifts ADAS Bay Max Lift
Flush-Mounted Scissor Lift
A purpose-built alignment and ADAS calibration scissor lift solution the ADAS Bay Max Lift is engineered to perform mechanical repair, wheel alignment, and ADAS calibration within a single bay space. Available in three configurations, 12K, 14K, and 16K with Extended Runways, designed to support passenger vehicles and light trucks in high-volume professional service environments.
Open front and rear runway configurations, heavy-duty rolling jacks, stainless-steel alignment hardware, reinforced runway construction, and integrated shop utility features to improve workflow efficiency and alignment Read More
Save Time &
Increase Efficiency
Eliminate inefficiencies in your shop by combining service, alignment, and ADAS calibration into a streamlined workflow.
One System.
Maximum Capability.
Perform inspection, alignment, and ADAS calibration without the need to constantly be moving the vehicle.
Built For Modern
Service Demands
Handle modern vehicles with the strength, accuracy, and flexibility required for complete vehicle service.
Flush-mount & H-Shape Configuration Maximizes Floor Space
Drive On / Off in Any Direction
Front and rear open runways paired with the unique flush-mount H-shape configuration of the Autel ADAS Bay Max maximizes versatility and usable floor space, allowing for all systems ADAS calibration.
100% Flexible Vehicle Placement
When recessed into the floor, the same space becomes the flat, unobstructed area required by the OEM’s per type of ADAS calibration.
Autel Academy Technical Training
Comprehensive in-person classroom and technical training for ADAS, Diagnostic and EV Diagnostic training now available. Our 2-day training course is intended for current or future owners of Autel equipment.
Vehicle Lifts 4-Post Alignment Lift
Heavy-Duty Vehicle Lift
The 4-Post Alignment Lift series is engineered for heavy-duty alignment service and high-volume professional shop environments, delivering exceptional lifting capability, alignment accuracy, and durability for passenger vehicles and light trucks. Available in open-post and closed-post configurations with 15K and 19K capacities, the series also includes extended runway models for increased vehicle coverage.
Designed with full-floating rear slip plates, stainless-steel front radius plates, rollback bars, and heavy-duty rolling jacks with integrated rail detents, these lifts support precise alignment procedures and reliable wheel-free service capability. Integrated tire inflation kits, LED undercarriage lighting, Read More
Compare all Autel vehicles lifts
| Features | 12K CAPACITY | 14K CAPACITY | 16K CAPACITY | 4-POST 15K CAPACITY | 4-POST 19K CAPACITY |
| CAPACITY | 12,000 lbs / 5.4 T | 14,000 lbs / 6.4 T | 16,000 lbs / 7.3 T | 15,000 lbs / 6.8 T | 19,000 lbs / 8.6 T |
| ALI CERTIFICATION | Yes | Yes | Yes | Yes | Yes |
| STYLE | Open Front & Rear | Open Front & Rear | Open Front & Rear | Open Front | Closed Front |
A RAISED HEIGHT | 74” (1,880mm) | 74” (1,880mm) | 74” (1,880mm) | 75” (1,905mm) | 74” (1,880mm) |
B LOWERED HEIGHT | 10 3/4” (273mm) SURFACE 0” (0mm) FLUSH | 10 3/4” (273mm) SURFACE 0” (0mm) FLUSH | 10 3/4” (273mm) SURFACE 0” (0mm) FLUSH | 8 3/8” (213mm) | 8 7/8” (225mm) |
C OVERALL LENGTH STANDARD | 242 3/4” (6,147mm) | 260 3/4” (6,604mm) | 260 3/4” (6,604mm) | 260 1/2” (6,617mm) | 274 3/8” (6,969mm) |
| OVERALL LENGTH EXTENDED | 18” (457mm) With Purchase of P/N: LPRE | 18” (457mm) With Purchase of P/N: LPRE | 275 3/4” (7,004mm) With Purchase of P/N: LPRE | 287 1/2” (7,303mm) | 301 3/8” (7,655mm) |
D DECK LENGTH STANDARD | 185” (4,699mm) | 203” (5,156mm) | 203” (5,156mm) | 211” (5,359mm) | 211” (5,359mm) |
| DECK LENGTH EXTENDED | — | — | 221” (5,613mm) | 238” (6,045mm) | 238” (6,045mm) |
E WIDTH BETWEEN RUNWAYS | 41” (1,041mm) | 41” (1,041mm) | 41” (1,041mm) | 41” (1,041mm) | 41” (1,041mm) |
F RUNWAY DECK WIDTH | 26” (660mm) | 26” (660mm) | 26” (660mm) | 26” (660mm) | 26” (660mm) |
G OVERALL WIDTH FRONT/REAR | 91 1/2” (2,324mm) | 91 1/2” (2,324mm) | 91 1/2” (2,324mm) | 143” / 137 1/2” (3,632mm) / (3,493mm) | 150” (3,810mm) |
H MAX COLUMN HEIGHT | — | — | — | 101 1/2” (2,565mm) | 86” (2,184mm) |
| MIN. 4 WHEEL ALIGNMENT WB | 84” (2,134mm) | 84” (2,134mm) | 84” (2,134mm) | 84” (2,134mm) | 84” (2,134mm) |
| MAX. 4 WHEEL ALIGNMENT WB | 164” (4,165mm) | 164” (4,165mm) | 164” (4,165mm) | 164” (4,165mm) | 164” (4,165mm) |
| MIN. 2 WHEEL ALIGNMENT WB STANDARD | 173" (4,394mm) | 173" (4,394mm) | 173" (4,394mm) | 177" (4,495mm) | 177" (4,495mm) |
| MAX. 2 WHEEL ALIGNMENT WB EXTENDED | — | — | — | 204" (5181mm) | 204" (5181mm) |
| LIFT TIME | 58 Seconds | 58 Seconds | 58 Seconds | 76 Seconds | 99 Seconds |
| POWER REQUIREMENTS | 230V, 60HZ, 1PH 30AMP | 230V, 60HZ, 1PH 30AMP | 230V, 60HZ, 1PH 30AMP | 230V, 60HZ, 1PH 25AMP | 230V, 60HZ, 1PH 25AMP |
| INCLUDED JACKING BEAM | 2 X 6,000 lbs / 2.7 T | 2 X 7,000 lbs / 3.2 T | 2 X 8,000 lbs / 3.6 T | 2 X 7,500 lbs / 3.5 T | 2 X 9,000 lbs / 4.1 T |
| SHIPPING WEIGHTS | 6,200 (2,812kg) | 6,400 (2,903kg) | 6,401 (2,903kg) | 5,600 (2,540kg) | 6,300 (2,857kg) |
| PART NUMBERS |
|
|
|
|
|
Vehicle Lift Accessories & Replacement Parts
Low Profile Ramp Extension Kit
Extends lift approach angle for smoother drive-on/off operation.
Stainless Steel Turn Plates
Replacement turn plates for 4-post and surface-mounted alignment systems.
Scissor Surface Mounting Kit
Designed to convert flushmount scissor lifts into surface-mount configuration.
Surface-Mount Approach Drive-Thru Ramp Kit
Enable drive-thru capability on 4-post alignment lifts with 15K lbs capacity.
Surface Mount Lift Drive-Thru Ramp Kit
Smoothly drive on/off the lift without repositioning. Designed for surface-mount scissor lifts.
